Product details
Technical Description
Essential product information, specifications, and recommended use before ordering.
Champion 06556 iPAC X1-5 & XL5LH 19/64" Screw Extractor / Left-Hand Drill Set
06556 is a Champion iPAC combination pairing one XL5LH left-hand twist drill in 19/64" with one X1 spiral flute screw extractor in size #5. This matched pair is designed to help remove broken screws, studs, bolts and pipe fittings with right-hand threads.
Pair Contents
1 Champion XL5LH-19/64 left-hand drill; 1 Champion X1-5 spiral flute screw extractor.
Key Benefits
- Matched drill and extractor sizes simplify selection for the targeted broken fastener.
- Left-hand XL5LH drilling can help loosen a broken or frozen bolt while drilling in reverse.
- X1 tapered spiral flutes force out right-hand threaded parts during counterclockwise rotation.
- Compact iPAC format keeps the two essential extraction tools together for repair and maintenance work.
- Made in USA for professional workshop and field use.
Applications
- Broken, frozen, rusty, seized or sheared right-hand threaded fasteners
- Steel, stainless steel and other tough materials
- Automotive repair, industrial maintenance, fabrication, HVAC and plumbing
- Bolts, screws, studs and pipe fittings
Technical Specifications
| Manufacturer part number | 06556 |
|---|---|
| Product type | iPAC left-hand drill and spiral flute screw extractor pair |
| Left-hand drill | Champion XL5LH-19/64 |
| Drill size | 19/64" |
| Screw extractor | Champion X1-5, spiral flute |
| Extractor size | #5 |
| Extraction direction | Counterclockwise / left-hand rotation |
| Country of origin | Made in USA |
| Package quantity | 1 pair |
How to Use
Secure the workpiece and drill the broken fastener with the 19/64" XL5LH bit in reverse. If the fastener does not loosen during drilling, insert the X1-5 spiral flute extractor into the pilot hole and turn counterclockwise with controlled hand-tool torque. Penetrating oil can help with rusty or corroded parts. Do not use an impact driver; wear eye protection and follow safe extraction practices.
Cutting tools and broken fasteners may chip or shatter if misused. Use the correct speed, feed, workholding and safety equipment for the material and machine.
Most Interesting Product Feature
Product highlight
Most Interesting Product Feature
- Matched XL5LH 19/64" left-hand drill and X1 #5 spiral flute extractor for staged broken-fastener removal
