Champion 06554 iPAC X1-3 & XL5LH 5/32" Screw Extractor / Left-Hand Drill Set
1 iPAC pair; XL5LH left-hand drill 5/32"; X1 spiral flute extractor #3
CHA-06554
Materials & Applications
Compatibility
Materials & Applications
Recommended use cases for this product across common industrial materials and jobsite applications.
Steel, stainless steel, cast iron, aluminum, machinery components, pipe fittings.
Broken bolt removal
stud extraction
pipe fitting removal
automotive repair
automotive repair
industrial maintenance
industrial maintenance
construction
fabrication
HVAC & Plumbing
Product details
Technical Description
Essential product information, specifications, and recommended use before ordering.
Champion X1-3 Spiral Flute Screw Extractor | 5/16" to 7/16" Bolt — Left-Hand Spiral Extraction
The X1-3 is a Champion X1 heavy-duty spiral-flute screw extractor sized for broken fasteners from 5/16" to 7/16". Its tapered spiral flutes tighten into the drilled hole as counterclockwise torque is applied, helping remove broken screws, bolts, studs and pipe fittings.
Drill a centered 5/32" pilot hole, insert the extractor and turn counterclockwise with a tap wrench, T-handle or adjustable wrench. The left-hand rotation and aggressive spiral profile are designed for controlled extraction of rusty, seized, sheared or overtightened right-hand threaded parts. Penetrating oil may help with corrosion.
Exact X1-Size Specifications
| Manufacturer part number | X1-3 |
|---|---|
| Extractor size | X1-3 |
| Flute style | Spiral flute, left-hand rotation |
| Small-end diameter | 1/8" |
| Large-end diameter | 1/4" |
| Overall length | 2-11/16" |
| Recommended drill size | 5/32" |
| Compatible bolt sizes | 5/16" to 7/16" |
| Compatible pipe sizes | N/A |
| Material | Hardened alloy steel |
| Country of origin | Made in USA |
How to Use This Spiral-Flute Extractor
Center-punch the broken fastener, drill only to the recommended pilot-hole size, then insert the X1-3. Turn counterclockwise using controlled hand-tool torque so the spiral flutes can bite and lift the fastener out. Do not use an impact driver; wear eye protection and follow safe extraction practices.
Always drill the recommended pilot hole before inserting the extractor. Cutting tools and broken fasteners may cause injury if misused.
Most Interesting Product Feature
Product highlight
Most Interesting Product Feature
- X1 extractors remove damaged screws without harming threads.
