Materials & Applications
Compatibility
Materials & Applications
Recommended use cases for this product across common industrial materials and jobsite applications.
Carbon steel
Structural steel
Mild steel plate
Cast steel, Stainless (with appropriate cutters)
Beam and plate holemaking
Field fabrication
Maintenance and repair (MRO)
Bridge and infrastructure work
Equipment and truck frame drilling
Product details
Technical Description
Essential product information, specifications, and recommended use before ordering.
Champion AC35 MiniBrute Magnetic Drill Press — Portable 1-3/8" x 2" Mag Drill for Steel Fabrication
The Champion AC35 MiniBrute Magnetic Drill Press is a lightweight, high-torque portable mag drill built for fast, accurate holemaking in structural steel, plate, beams and fabrication work. With a 1-3/8" diameter x 2" depth of cut capacity, 600 RPM motor speed and 2,200 lb magnetic holding force, the AC35 delivers dependable performance in the shop, on-site and in maintenance applications.
At only 23 lb, the AC35 MiniBrute is easy to move around the jobsite while still offering the cutting capacity needed for common annular cutter work. It accepts standard 3/4" Weldon shank annular cutters and includes a quick-change arbor for faster cutter swaps, helping reduce downtime between hole sizes.
This Champion RotoBrute magnetic drill is ideal for contractors, metal fabricators, maintenance teams and industrial users who need a compact mag drill with serious cutting capability. It can also be converted from annular cutter use to twist drilling with the Champion QX1220 drill/chuck adapter, sold separately.
Key Benefits
- 1-3/8" diameter x 2" depth capacity for annular cutter drilling in steel.
- Only 23 lb for easier handling, transport and jobsite use.
- 2,200 lb magnetic holding force for stable drilling on ferrous surfaces.
- 600 RPM single-speed motor optimized for annular cutter performance.
- Quick-change 3/4" Weldon arbor for fast, secure cutter changes.
- External coolant bottle included for cleaner cutting and improved tool life.
- Converts to twist drilling with the QX1220 drill/chuck adapter, sold separately.
Included with the AC35 MiniBrute
- Carrying case
- Quick-release / quick-change arbor
- External coolant bottle
- Safety guard
- Safety chain
- Hex keys
Technical Specifications
| Product Type | Portable Magnetic Drill Press |
|---|---|
| Model | Champion AC35 MiniBrute |
| Annular Cutter Capacity | 1-3/8" diameter x 2" depth of cut |
| Motor Power | 1100–1200 W class |
| No-Load Speed | 600 RPM |
| Magnetic Holding Force | 2,200 lb |
| Weight | 23 lb |
| Arbor Compatibility | 3/4" Weldon shank annular cutters |
| Twist Drill Adapter | QX1220 drill/chuck adapter, sold separately |
| Recommended Applications | Structural steel, plate, beams, fabrication, construction, maintenance and repair |
Why Choose the Champion AC35?
The AC35 is built for users who want a compact magnetic drill press without sacrificing real cutting capacity. Its combination of low weight, strong magnetic adhesion, 3/4" Weldon compatibility and quick-change arbor makes it a practical choice for steel erection, fabrication shops, industrial maintenance and field drilling where portability matters.
Always secure the magnetic base properly, use the supplied safety chain, apply cutting fluid when drilling and wear appropriate PPE. Follow Champion operating instructions before use.
Frequently Asked Questions
What is the cutting capacity of the Champion AC35 MiniBrute?
The Champion AC35 MiniBrute magnetic drill press has an annular cutter capacity of 1-3/8" diameter x 2" depth of cut, making it suitable for structural steel, plate, beams, fabrication and maintenance drilling.
What type of cutters does the Champion AC35 use?
The AC35 is designed for 3/4" Weldon shank annular cutters. It includes a quick-change arbor for fast and secure cutter installation.
Can the Champion AC35 drill with regular twist drill bits?
Yes. The Champion AC35 can be converted for twist drilling by using the Champion QX1220 drill/chuck adapter, sold separately.
How much does the Champion AC35 magnetic drill press weigh?
The AC35 MiniBrute weighs approximately 23 lb, making it a compact and portable mag drill for field work, construction, fabrication shops and maintenance teams.
What is the magnetic holding force of the Champion AC35?
The Champion AC35 has a magnetic holding force of 2,200 lb, helping keep the drill stable when used properly on clean, flat ferrous material.
What RPM does the Champion AC35 run at?
The Champion AC35 runs at 600 RPM, a speed well suited for annular cutter drilling in steel and industrial holemaking applications.
What comes included with the Champion AC35 MiniBrute?
The AC35 MiniBrute typically includes a carrying case, quick-change arbor, external coolant bottle, safety guard, safety chain and hex keys.
Is the Champion AC35 good for structural steel drilling?
Yes. The Champion AC35 is built for drilling holes in structural steel, plate, beams, fabrication work, construction jobs and industrial maintenance applications.
Most Interesting Product Feature
Product highlight
Most Interesting Product Feature
- Includes: Carrying Case, Hex Keys Safety Chain, External Coolant Bottle, Safety Guard, Quick Release Arbor
